24 m/min NC Servo Feeder Machine For Press Machine

    Buy cheap 24 m/min NC Servo Feeder Machine For Press Machine from wholesalers

    Buy cheap 24 m/min NC Servo Feeder Machine For Press Machine from wholesalers
    • Buy cheap 24 m/min NC Servo Feeder Machine For Press Machine from wholesalers
    • Buy cheap 24 m/min NC Servo Feeder Machine For Press Machine from wholesalers
    • Buy cheap 24 m/min NC Servo Feeder Machine For Press Machine from wholesalers

    24 m/min NC Servo Feeder Machine For Press Machine

    Ask Lasest Price
    Brand Name : RUIHUI
    Model Number : MAC3-400
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P
    Supply Ability : 10 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    24 m/min NC Servo Feeder Machine For Press Machine


    Factory Direct Sale Auto Feeder For Press Machine, Punch Servo Leveling Feeder RUIHUI


    Three-in-one feeder Dongguan RUIHUI has an annual warranty of one year, you can buy it with peace of mind, and use it with confidence. After-sales service can be solved within 24 hours in nearby areas and within 48 hours from other provinces. Quality and service are guaranteed, low risk


    Features of stamping three-in-one feeder:

    1. Convenient and fast loading and unloading: equipped with a loading trolley: the material is smoothly moved to the expansion and contraction structure of the uncoiler's main shaft, which is used to hold the material when uncoiling, so that the material belt can smoothly enter the leveling machine.

    2. Exquisite structure and space saving: The three-in-one feeder is composed of three functions of rack, leveling and feeding. Its loading, feeding, blocking, folding, leveling, feeding and reloading are all controlled by One person can complete the point-controlled operation on the independent console, which greatly saves labor and effectively solves the problem of inconsistent leveling and feeding, achieving high-speed leveling and feeding effects, and the overall appearance is strong and beautiful.

    3. Easy to operate and easy to learn: The operation panel adopts a color LCD display, a large-size touch screen, and a high-definition operation screen. It automatically adjusts what size is required to enter it. It is very intelligent and can be operated with peace of mind even with the operation protection system. . It is also equipped with end detection function to avoid false punching and protect the stamping die.
    4. High discharging speed: The material rack part adopts three sets of photoelectric automatic control to ensure synchronization with the leveling and feeding part, effectively realizing high-speed uncoiling, leveling and feeding, and improving the discharging speed.

    RUIHUI feeder manufacturer to cater to the demand of the market, independent creative, developed different thickness optional triad feeder: the triad of sheet feeder (0.3-3.2 mm), medium plate triad feeder (0.5-4.5 mm), thick plate triad feeder (0.6-6 mm), high strength triad feeder (for yield strength strong material), customers can according to the different material thickness, material choosing suitable models



    ModelMAC3-400MAC3-600MAC3-800MAC3-1000
    Stock Width(mm)50~40050~60070~80070~1000
    Stock Thickness(mm)0.3~4.50.3~4.50.3~4.50.3~4.5
    Max.Coil Weight(kg)50005000500070007000
    Max.Coil O.D.(mm)Φ1400Φ1400Φ1400Φ1400
    Coil I.D.(mm)Φ508Φ508Φ508Φ508
    Feed Length(mm)~500*~500*~500*~500*
    Max.Line Speed(m/min)16~2416~2416~2416~24
    Work Roll Number(piece)up 4 / down 3up 4 / down 3up 4 / down 3up 4 / down 3
    Feed Roll number(set)1111
    Main MotorAC4.4AC4.4AC5.5C7.5
    Mandrel Expansionhydraulichydraulichydraulichydraulic
    Reel Motor(kw)2.22.22.23.73.7
    Power(v)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.49

    Straightening Performance:

    ModelMAC3-400MAC3-600MAC3-800MAC3-1000
    Stock Thickness
    (mm)
    0.3~0.84006008001000
    1.0750
    1.2700600
    1.6590480430
    1.8500420380
    2.0430370330
    2.3360320290
    2.8370290250230
    3.2300250220200
    4.5160160150110

    *The avove flgures are the material having yield strength of 245N/mm2 max.


    RUIHUI founded in 2000, the technology of automation periphery is from Japan.Now RUIHUI is a Japanese brand and the same technique of sheet metal stamping surrounding automation equipment manufacturer. RUIHUI has been learning Japan and Germany technology, and useing high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and reihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industy,and investment less.

    FAQ:


    Q1:What kinds of machines do you have?

    Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener

    Feeder,Transfer systems,Press Feeding Line., etc

    Q2:Is your equipment standard or customized?

    Both, we can OEM & ODM with customers.

    Q3:What are your equipments certification?

    All our items are coming with CE certifications.

    Q4:How did your company's quality system work?

    “QUALITY IS OUR CULTURE” Our quality is not the best in the world, and the price is not the

    cheapest. But we can provide you excellent products to defeat your competitors.

    Q5:How long is the warranty period of the machine?

    We offer free service with a warranty period of one year, If it is operate in reasonable, the

    machine can be used more than 10 years.

    Q6: Is it possible to be a foreign agent and distributor?

    If you are confidence and excellent service for after-sales, then welcome to be our agents or

    distributors all over the world.

    Q7:What’s your payment?

    T/T,D/P,L/C,Western Union., etc

    Q8:What’s the delivery?

    “TIME IS GOLD” for you and for us, so we have professional team work and production line can

    make nice quality in short time.

    Service:

    1. Pre-Sales Service:We have professional designers to meet the different requirement.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.
