Because the servo feeder adopts the numerical control system to accurately control the feeding roller, it has the advantages of higher feeding precision, better stability, easier operation and wider application range than other feeding devices.

1. Pneumatic NC servo feeder: This is the most used servo feeder model in the stamping industry. It uses cylinder clamping to relax, not subject to installation restrictions. It can be used not only with almost all presses, but also with hydraulic presses and shears. However, due to the use of cylinder push-pull form relaxation, there is a certain response time, so it is not suitable for high-speed feeding occasions.

2. Mechanical NC servo feeder: The mechanical rod used for relaxation mode is relaxed, the relaxation speed is fast, and the installation is limited. It is mainly used with the punching machine for short-step high-speed feeding. It is easier to relax and debug. Both mechanical NC and pneumatic NC can be used.

3. Pivot-type NC servo feeder: It is specially developed for the production and production of wafer cutting customers. It adopts Japanese imported servo and adopts computer closed-circuit feedback control to ensure the accuracy is within ±0.02mm. The material is conveyed on a two-dimensional plane, so that the wafers are rounded and rounded, and the flatness of the wafer is ensured, thereby maximizing material utilization.

4. Thick plate type NC servo feeder: It is specially developed for conveying 4.5-6mm thick plate. Compared with ordinary NC servo feeder, it not only increases the power of the motor but also the upper and lower gear teeth of the feed roller. In addition to the angle, a pair of feed rollers has been added, which fundamentally eliminates the slippage of the thick plate material conveyance and the instability is unstable.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
