    Automatic 3 in 1 Aluminum 0.6-6.0 mm Thickness Feeder Decoiler and Straightener Machine

    Ask Lasest Price
    Brand Name : RUIHUI
    Certification : CE Certificate
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    Model Number : MAC4-800F
    • Product Details
    • Company Profile

    Automatic 3 in 1 Aluminum 0.6-6.0 mm Thickness Feeder Decoiler and Straightener Machine

    Automatic 3 in 1 Aluminum 0.6-6.0 mm Thickness Feeder Decoiler and Straightener Machine


    The 3-in-1 feeder is a fully automatic feeding device that integrates feeding, rectification and material racks. It not only improves production efficiency but also reduces labor. It is an efficient product.
    3-in-1 feeder loading:
    1. Place the material on the crane and stabilize it.
    2. According to the oil pressure relaxation, reduce the material frame to a certain diameter, slowly feed the material into the main shaft of the material rack, and make the center of the material coincide with the scale on the tile. Stop the advance and remove the crane.
    3. the material is placed well, according to the oil pressure expansion and tightening material, the material is in a state of tension.

    4. Press down on the hydraulic pressure press arm and place the knob in the automatic position. Raise the support arm and remove the material packing tie, pay attention to the material rebound. (The hydraulic pressure arm must be pressed down, otherwise it may cause the material to loosen and pay attention to the position of the person.)

    3-in-1 feeder
    Specification:

    ModelMAC2-400MAC2-500MAC2-600MAC2-800
    Stock Width(mm)50-40050-50050-60050-800
    Stock Thickness(mm)0.3~3.20.3-3.20.3-3.2-3.2
    Max.Coil Weight(kg)300030003000500050007000
    Max.Coil O.D.(mm)120012001200
    Coil I.D.(mm)88508508
    Feed Length(mm)~500*~500*~500*~500*
    Max. Line Speed(m/min)16-2416-2416-2416-24
    Work Roll Number(pieces)upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    Feed Roll Number(set)1111
    Main Motor(kw)AC2.9AC2.9AC4.4AC4.4
    Mandrel Expansionhydraulichydraulichydraulichydraulic
    Reel Motor(kw)1.51.51.52.22.23.7
    Power(V)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.49


    Straigtening performance:

    tock Thicknees (mm)Stock Width (mm)
    0.3400500600800
    0.4
    0.6
    0.8
    1.0
    1.2
    1.4
    1.6470470
    1.8400400
    2.0360360
    2.3300300300300
    2.5230230230230
    2.8150150150150
    3.2110110110110


    *1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

    1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
    2. After-Sales service:We have an efficient team to meet 24*7 all day service.
    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
    4. Engineers can provide service machinery overseas.
