    Stamping Machine MAC2-600 Series NC Servo Decoiler Straightener Feeder Metal Forming


    Product Description
    Stamping Machine MAC2-600 Series NC Servo Decoiler Straightener Feeder Metal Forming

    1.Description

    High Degree of Flatness

    Combining the power of the hcavy duty HL unit with the straightening performance of 11work rolls(6 upper and 5 lower),the HL unit gives material a high degree of flatness to the materials from up to 6.0mm thick.

    Geared Motor with Inverter Control

    Geared Motor with Inverter control allows the feed speed to change easily,in addition,a direct drive machanism without a chain and precision gear has been adopted.These features create maximum smoothness of the work roll movement producing a precise end product.

    2.Specification

    Specification
    ModelMAC2-300MAC2-400MAC2-500MAC2-600
    Stock Width(mm)50-30050-40050-50050-600
    Stock Thickness(mm)0.3-3.2
    Max.Coil Weight(kg)30003000-5000
    Max.Coil O.D.(mm)Φ1200
    Coil I.D.(mm)Φ508
    Feed Length(mm)~400*

    Max.Line

    Speed(m/min)

    16-24

    Work Roll

    Number(piece)

    uppper6 / lower5

    Feed Roll

    number(pcs)

    1
    Main MotorAC2.9AC4.4
    Mandrel ExpansionHydraulic
    Reel Motor(kw)1.52.2
    Power(V)3Phase 220V/380V/50HZ
    Operating Air(Mpa)0.49
    Straightening Performance
    Stock Width(mm)

    MAC2-300

    MAC2-400MAC2-500MAC2-600

    Stock

    Thickness

    (mm)

    0.3300400500600
    0.4
    0.6
    0.8
    1
    1.2
    1.4
    1.6470
    1.8400
    2.0360
    2.3300300300
    2.5230230230230
    2.8150150150150
    3.2110110110110

    Remark:

    1.(Penumatic):Option in case of penumatic mandrel expansion is provided,refer to coil weitht().

    2.The above flgures are the material having yield strength of 392N/mm2 max.

    3.Specification are subject to change for improvement without notice.
