Pneumatic NC servo feeder is the most convenient automatic feeding equipment in the stamping industry with the most stable performance, the highest feeding precision, the most suitable equipment, and the easiest installation and commissioning.

It is widely used in the stamping industry, and it is also the most used feeder type for stamping owners. The pneumatic NC servo feeder produced by Ruihui Machinery is one of the best.

Ruihui pneumatic NC servo feeder has better performance advantages than other manufacturers' feeders:

1. When the punch presses the plate, the pneumatic cylinder uses the force of the air pressure to move the piston downward. Therefore, when the pneumatic cylinder moves downward, the spiral arm is pulled by the fixed shaft, so that the spiral arm is tilted downward by an angle. .

At the same time, the clamping roller is moved upward by the principle of eccentricity of the eccentric shaft to prevent the roller from feeding back the NC servo motor due to the reverse rotation of the plate punching, which causes the NC servo motor to calculate the feeding progress error and affect the accuracy of the feeding.

2. Each time the stamping is performed, the pneumatic cylinder can be automatically restored to the original position. With the adjustment of the reference line of the pneumatic cylinder according to the thickness of different metal plates, it can have the function of returning to zero at any time.

It can effectively prevent the unnecessary collision between the feeding roller and the clamping roller, generate noise, and make the feeding process more precise.

3. When changing the plate for different thickness for stamping processing, it can be adjusted by another pneumatic cylinder. When the pneumatic cylinder is raised, the arm can move the feeder roller downward by the eccentric wheel.

In order to achieve different distances for adjusting the thickness of the sheet, the user can adjust the distance of the rise of the pneumatic cylinder according to the different thickness of the material, and the operation is quite easy.

4. Not only can the calculation of the NC servo motor be more accurate, but also the pneumatic cylinder can be adjusted immediately when adjusting the thickness of the feed, which is quite convenient in operation.

When the Ruihui NC servo feeder is actually used, the distance, speed and number of feedings are set on the independent electric control box. Then, the servo motor drives the driven gear through the belt through the driving roller to drive the driven roller to rotate the driving roller. .

The plate can be fed to the pinch roller and the active roller according to the preset distance and speed. When the punch presses the plate, the pneumatic cylinder uses the force of the air pressure to move the piston downward.

Therefore, when the pneumatic cylinder moves downward, the arm is pulled by the fixed shaft, so that the arm is tilted downward by an angle, and the pinch roller is moved upward by the principle of eccentricity of the eccentric wheel.

Preventing the roller from feeding back the NC servo motor due to the reverse rotation of the plate stamping, which causes the NC servo motor to calculate the feeding progress error and affect the accuracy of the feeding;

When the NC servo feeder performs a stamping, the pneumatic cylinder can be automatically restored to the original position, which has the function of returning to zero, which makes the feeding process more precise.

Furthermore, when the thickness of each sheet is changed, it can be adjusted by another pneumatic cylinder. When the pneumatic cylinder is raised, the arm can be moved downward by the eccentric pulling the driving roller.

In order to achieve different distances for adjusting the thickness of the sheet, the user can adjust the distance of the rise of the pneumatic cylinder according to the different thickness of the sheet, the feeding precision is high, the stability is good, and the operation and use are extremely simple.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.
