The conventional gear feeder adopts a two-wheel double-drive feed transmission system. During use, the upper and lower rollers have a driving function, but the gears of the gears between the second gear sets are changed due to the change of the thickness of the material to be conveyed.

In the end, the upper roller does not play the driving role, and the gear angle error changes greatly, which can not realize the true double drive. The Ruihui gear feeder is changed from the traditional two-wheel drive mode to the four-wheel four-wheel drive mode. Compared with the traditional gear feeder, it has three significant advantages:

1. Since the feeding drive system adds the second roller set and the second gear combination excessive gear set, the two sets of roller sets all play the driving role, forming four-wheel four-wheel drive, and the friction coefficient of the roller surface can be controlled, thereby greatly improving Feed line speed.

2. Improve the feeding ability of the material to be sent by the feeder, such as the material to be sent in the width of the material, and the conveying capacity of the material to be sent in the range of 0-1 mm. Moreover, the feed line speed is not affected by these materials.

3. Due to the use of high-precision grinding gears, the transmission error is reduced. The hollow roller is used to reduce the quality and inertia of the feeding transmission system, improve the feeding accuracy, achieve higher speed feeding and improve production efficiency.

Since the surface of the roller is processed, the wear resistance of the roller is increased, the friction coefficient is increased, and the driving force of the roller is larger and it is not easy to slip.

For the extra-wide material to be fed, the contact area between the roller and the sheet material is increased, thereby improving the jog braking performance of the feeder and reducing the sliding distance of the material to be conveyed.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
