NC servo yaw is a test case for roller feeder adjustment

1. Start the correcting machine or material holder and slowly release the material.

2. Adjust the position of the two stopper wheels according to the width of the material, so as not to hinder the operation of the material.

3. Will relax the cylinder on the platform, put the material between the upper and lower rollers, put down the cylinder to press the material, adjust the air source pressure gauge to avoid the material is not tight and slip, resulting in inaccurate feeding. When the thickness of the material changes, it must be readjusted. .

4. After setting the feeding length, look at the actual situation, and set the feeding speed accordingly. The method of setting is described in detail in the previous section.

5. After the relevant parameters of the feeding are set, the actual feeding length is not the same as the set value due to the number of the divisor. Therefore, in the manual mode, press the feeding test, punching, stroke, stamping, and adjusting the feeding. Actual length

6. The adjustment of the feed start is adjusted by the rotary cam of the press. The so-called feed start signal is to start at the angle of the punch crankshaft.

NC servo yaw is a note for the roller feeder

1. The electrical equipment works under normal voltage. If the voltage is constantly changing, the life of the electrical components will be seriously shortened and the failure rate will increase sharply.

2. This machine must not be overloaded. The operator at the production site must operate in accordance with the instructions in this instruction manual. In particular, it is necessary to master the essentials and safety when loading, and must be supervised by the person in charge.

3. The linear guide of the yaw unit and the ball screw are precision components, and it is strictly forbidden to hit the collision. Also check for loose screws and lubricated oil before work every day.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
