Leveling feeder, auto stamping parts, Guangdong Ruihui precision stamping processing

The molds used in the field of precision stamping are equipped with guide pins to correct the length of the material fed into the mold each time to ensure the precision of the stamping process.

If this correction is to be realized, the feeder must be equipped with a relaxation device to achieve the matching. After the tip of the mold guide pin enters the stamping material, the feeder clamp is in a relaxed state, and the guide pin can correct the error in time. And this relaxation time is the angle of relaxation of the feeder.

In fact, the reason for this problem is very simple, that is, the stamping process of each set of molds is different, so the thickness of the mold, the length of the guide pin is different, and the change of the length of the guide pin will make the time for inserting the guide pin into the material.

This time has changed. If the time of relaxing the angle is still not properly realized by the previous one, the guiding function of the guiding pin can not be realized, which ultimately leads to the inaccuracy of the feeding length.

Therefore, the adjustment of the feeding angle of the feeder after the mold is changed is an indispensable part. The adjustment standard is to relax when the guiding pin of the mold enters the hole of the material.

When the mold is raised, the positioner needle is the basic criterion for the material to be clamped in front of the needle hole of the material, so as to ensure the high precision of the punch press production.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
