    Disc Feeder Steel Plate Straightening Machine Metal Roll Punch Stamping Equipment

    Ask Lasest Price
    Brand Name : RUIHUI
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Disc Feeder Steel Plate Straightening Machine Metal Roll Punch Stamping Equipment


    Disc Feeder, Metal Roll Stamping, Guangdong Punch Stamping Feeding Equipment


    Although the name of the feeder of the disc feeder is actually a material rack, the name of the disc feeder is due to the fact that it uses a horizontal disc to horizontally place the coil, which can be quickly transported to the subsequent matching machine. material.


    As the only horizontal material rack in the stamping industry, the disc feeder is the rack equipment developed by Ruihui Machinery for thin plate, narrow material and high speed stamping.


    The utility model has the advantages of fast unwinding speed, no restriction on the inner diameter of the material, simple stacking, multi-roll stacking, simple operation, perfect speed synchronization by frequency conversion and speed regulation, and no scratching on the surface edge of the material.


    1. The disc feeder has a fast unwinding speed and is suitable for use with any high-speed punching machine; the high-speed punching press has a fast stamping speed, which puts a rigid requirement on the running speed of the material rack and the leveling machine, and the feeding speed can reach 30m/min makes it suitable for any high-speed punch press production.


    2. The disc feeder is not limited by the inner diameter of the coil. The coils can be stacked, and the feeding is simple and quick, and the refueling time is greatly saved.


    Vertical material racks are all used in the tensioning and unloading method of the drum. Therefore, there is strict requirement on the inner diameter of the coil, and only one coil can be placed in one coil, and manual manual tensioning material is required. Rolls, loading is cumbersome, and it takes a long time to refuel a roll of material.


    3. The disc feeder tracker can detect the unwinding speed in real time and automatically adjust the speed of the inverter to achieve the perfect match with the stamping production of the high-speed punch.


    4, can be customized double-layer disc feeder, to meet the needs of customers double belt stamping production. The double-material belt stamping production line refers to the punching production of two strips in one time, and is the most advanced stamping production process.


    It is also the inevitable trend of the industry, and the double-material belt stamping requires double-tape unwinding, leveling and feeding equipment. The double-layer disc feeder is the only one that can realize the double-tape simultaneous unwinding.

    disc feeder

    disc feeder


    Specification:

    ModelMAC2-400MAC2-500MAC2-600MAC2-800
    Stock Width(mm)50-40050-50050-60050-800
    Stock Thickness(mm)0.3~3.20.3-3.20.3-3.2-3.2
    Max.Coil Weight(kg)300030003000500050007000
    Max.Coil O.D.(mm)120012001200
    Coil I.D.(mm)88508508
    Feed Length(mm)~500*~500*~500*~500*
    Max. Line Speed(m/min)16-2416-2416-2416-24
    Work Roll Number(pieces)upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    Feed Roll Number(set)1111
    Main Motor(kw)AC2.9AC2.9AC4.4AC4.4
    Mandrel Expansionhydraulichydraulichydraulichydraulic
    Reel Motor(kw)1.51.51.52.22.23.7
    Power(V)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.49


    Straigtening performance:

    tock Thicknees (mm)Stock Width (mm)
    0.3400500600800
    0.4
    0.6
    0.8
    1.0
    1.2
    1.4
    1.6470470
    1.8400400
    2.0360360
    2.3300300300300
    2.5230230230230
    2.8150150150150
    3.2110110110110


    *1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

    1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
    2. After-Sales service:We have an efficient team to meet 24*7 all day service.
    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
    4. Engineers can provide service machinery overseas.
