Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing

    Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers

    Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers
    • Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers
    • Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers
    • Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers
    • Buy cheap Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing from wholesalers

    Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing

    Ask Lasest Price
    Brand Name : RUIHUI
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing


    Automation Stamping Press Feeder Equipment Stainless Steel Roller Processing


    Although the NC feeder is a new type of feeding equipment, because of its adjustable step, easy operation, wide applicability, stable and reliable feeding accuracy, it has become the most popular punching equipment for stamping customers.


    The operation of the NC feeder is controlled by the servo motor to feed the feed roller. Because the output torque of the servo motor itself is small and cannot meet the needs of use, a certain deceleration should be performed between the feed roller and the servo motor of the feeder to achieve the use of increased torque. Claim.


    Ruihui Machinery optimizes and improves the structure of the drive mechanism of the NC feeder. The servo motor adopts the secondary reduction drive for the feed roller, and the first stage is the synchronous belt drive. The reduction ratio is 1/3, the first gear is the gear transmission, and the reduction ratio is For 1/3, increase the transmission torque.


    The reduction ratio of the transmission can reach 1/9, which can avoid the problems caused by adopting different structures in the traditional NC feeder, effectively and reliably achieve the high-efficiency transmission effect, and the maintenance is convenient and convenient afterwards.


    Moreover, the improved feeding accuracy of the NC feeder can reach the feeding precision of the synchronous wheel transmission, and the reduction ratio can be produced as needed, and there is no problem that it is difficult to install due to insufficient installation space, and the reduction ratio can be reduced. The power of the small servo motor can save costs and truly give customers peace of mind and benefits.


    products:

    NC feeder

    NC feeder


    specifications

    ModelStock Width (mm)Coil Weight (kg)Motor
    (kw)
    Pressing ArmCoiling block expansion modeMaterial ID (mm)Material OD (mm)
    ME-20070-2005000.375PneumaticManual/Hydraulic508930
    ME-30070-3008000.75PneumaticManual508930
    ME-40070-40010000.75PneumaticManual/Hydraulic508930
    ME-50070-50015001.5PneumaticManual5081200
    ME-600100-60030001.5PneumaticManual5081200
    ME-800100-80050002.2PneumaticManual5081200

    FAQ:

    Q1:What kinds of machines do you have?
    Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener Feeder,Transfer systems,Press Feeding Line., etc
    Q2:Is your equipment standard or customized?
    Both, we can OEM & ODM with customers.
    Q3:What are your equipments certification?
    All our items are coming with CE certifications.
    Q4:How did your company's quality system work?
    "QUALITY IS OUR CULTURE" Our quality is not the best in the world, and the price is not the cheapest. But we can provide you excellent products to defeat your competitors.
    Q5:How long is the warranty period of the machine?
    We offer free service with a warranty period of one year, If it is operate in reasonable, the machine can be used more than 10 years.
    Q6: Is it possible to be a foreign agent and distributor?
    If you are confidence and excellent service for after-sales, then welcome to be our agents or distributors all over the world.
    Q7:What's your payment?
    T/T,D/P,L/C,Western Union., etc
    Q8:What's the delivery?
    "TIME IS GOLD" for you and for us, so we have professional team work and production line can make nice quality in short time.


    1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
    2. After-Sales service:We have an efficient team to meet 24*7 all day service.
    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
    4. Engineers can provide service machinery overseas.
