    Coil Processing Decoiler Straightener Feeder Roller Feeder Stamping Automation Equipment

    Ask Lasest Price
    Brand Name : RUIHUI
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Coil Processing Decoiler Straightener Feeder Roller Feeder Stamping Automation Equipment

    Roller feeder, coil material processing, stamping automation equipment


    One end of the feeding roller of the roller feeder is respectively connected with the transmission shaft to drive the feeding roller to rotate, and the relative movement between the upper and lower feeding rollers drives the material to be moved forward to achieve the purpose of feeding.


    A one-way bearing is connected between the feeding roller and the transmission shaft, and the one-way bearing controls the feeding roller to perform one-way rotation, because the rocker arm is reciprocating up and down, and the feeding roller is only allowed to feed forward, so installing the one-way bearing is The role of directional rotation.


    When the punching machine is moving downward, the mold is closed. Due to the control of the one-way bearing, the feeding roller does not move at this time, the material is stationary, and the mold is subjected to pressure processing. When the punching machine is moved upward, the workpiece is processed, the mold is opened, and the feeding roller is driven. Start turning and feed the material into the mold according to the feed amount of the adjusted step.


    In actual use, the roller feeder is fixed to the punching table side by a mounting plate, which can be adjusted according to the width, thickness and height of the material. The feed amount of the material can pass through the output shaft of the punching machine according to the step of the die. Passed to the feeder.


    The material of the feeder is smoothly fed into the mold, and the feeding speed is fast, the precision is high, the stability is good, and the failure rate is low, which fundamentally solves the problem of multi-step stamping feeding.


    Products:

    punching machine

    punching machine


    Specification:

    ModelMAC2-400MAC2-500MAC2-600MAC2-800
    Stock Width(mm)50-40050-50050-60050-800
    Stock Thickness(mm)0.3~3.20.3-3.20.3-3.2-3.2
    Max.Coil Weight(kg)300030003000500050007000
    Max.Coil O.D.(mm)120012001200
    Coil I.D.(mm)88508508
    Feed Length(mm)~500*~500*~500*~500*
    Max. Line Speed(m/min)16-2416-2416-2416-24
    Work Roll Number(pieces)upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    upper 6
    lower 5
    Feed Roll Number(set)1111
    Main Motor(kw)AC2.9AC2.9AC4.4AC4.4
    Mandrel Expansionhydraulichydraulichydraulichydraulic
    Reel Motor(kw)1.51.51.52.22.23.7
    Power(V)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.49


    Straigtening performance:

    tock Thicknees (mm)Stock Width (mm)
    0.3400500600800
    0.4
    0.6
    0.8
    1.0
    1.2
    1.4
    1.6470470
    1.8400400
    2.0360360
    2.3300300300300
    2.5230230230230
    2.8150150150150
    3.2110110110110


    *1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

    1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.
