Leveling machine leveling accuracy, sheet straightening machine, punching machine

In order to ensure the leveling accuracy of the leveling machine, the diameter of the leveling roller is not large. When the material width is too large, most of the flattening coils have a certain curvature, not a flat shape.

Especially for diagonally twisted coils, it is impossible to level. For the above defects, Ruihui leveling machine is equipped with an auxiliary leveling roller set when the width exceeds 300mm. The center of the upper and lower auxiliary rollers is in the vertical direction. Arranged in a misplaced manner.

The flattening roller acts as a reinforcing support to avoid deformation of the leveling roller and increase the downforce when the leveling machine is leveled, and the auxiliary roller can be freely adjusted directly through the adjusting wheel fixed on the upper template, thereby ensuring Can level all kinds of irregular coils.

When the leveling machine with the auxiliary leveling roller is used, the flattened material is flattened with the upper roller and the lower roller on the roller bracket, and then enters the auxiliary leveling roller, and the auxiliary leveling roller is further flattened.

If the flattened web is not completely flat, the adjustment device fixed to the upper template can be adjusted to achieve complete flatness.

The adjustment process is as follows: rotating the adjusting wheel to drive the spring to rotate, and because the vertical position of the spring is fixed, the adjusting rod that drives the rotating sleeve moves up and down.

The adjustment further drives the one or both ends of the adjustment sliding block to move up and down, so that the roller slider fixed with the auxiliary driving the flattening roller changes the vertical relative position of the two ends to achieve a completely flattening effect.

Products:

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi

RUIHUI founded in 2000, the technology of automation periphery is from Japan. RUIHUI has been learning Japan and Germany technology, and using high standards of principle in the parts selection, for assembly process and spare parts, adhere to the requirements in accordance with the original design standard, and into each manufacturing process. In 20 years has accumulated experience and excellent design ability of Japanese engineers guided ruihui highly responsible for Industry and ruihui strong executive team, created a batch of well-known auto parts manufacturers, allowing them to reach the high level in same industry，and investment less.

Customer case

Manufacturing industry; the United States Lear, Honda factory, Ford factory, GAC Group, Chongqing Changan, Wuhan Shenlong, BMW Brilliance, FAW Volkswagen, Beijing Hyundai.

And other household appliances manufacturers; such as GREE, Haier, Midea, Chigo Air conditioning.

hardware manufacturers; such as the United States Southco, are Zhongtai industrial manufacturers success cooperation case.

RUIHUI QUALITY is not the best in the world, and the price is not the cheapest. But we can provide excellent products to help you defeat your competitors.

Products: Feeder machine, Straightener machine, Uncoiler machine, Decoiler with Straightener, 3 in 1 NC Straightener Feeder, Coil handling system, Transfer system, Robot System, to meet the market needs of customers, improve work efficiency, reduce the burden of enterprise management personnel, maintenance of production safety and the customer staff made a significant contribution.

At present the company to further develop the market, at the end of 2017, the total investment reached 30 million USD, plant area of more than 20 thousand square meters, in order to meet the demand on the market and lay a solid foundation after.

Why choose us?

1^st,We have a high level of technical research and development team;

2^nd,We can provide the design and planning of the whole plant to realize the turnkey project;

3^rd, our philosophy: quality is the social responsibility;

4^th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;

5^th,We have a highly effective after-sales service team and get customer approval.
