    Clip Type Automatic Press Feeding Equipment High Punching Precision Smooth Feeding

    Ask Lasest Price
    Brand Name : RUIHUI
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Clip Type Automatic Press Feeding Equipment High Punching Precision Smooth Feeding


    Clip Type Automatic Press Feeding Equipment High Punching Precision Smooth Feeding


    The clip feeder is driven by a cam and uses a curved cam and three plate cams to achieve high-speed and smooth feeding.


    Built-in inspection mechanism to detect blockage or deformation of materials. The 165 degree feed section angle allows the material to stay longer in the press.


    Combined with the mold guiding pin, the release time of the material during guiding can be adjusted. It can transport round or square wires.


    Advantages of the clip feeder: The feeding speed can be synchronized with the punching machine, and the speed can be as fast as 1200 times/min. The feeding precision is higher, more stable, and the machine is lighter and smaller.


    Suitable for feeding processing of ultra-thin materials, such as connectors, lead frames, and inspection parts, such as high-precision and high-speed stamping.


    Disadvantages of the clip feeder: generally used for material feeding in 0.1~0.5mm, the scope of application is small, and the price is relatively high.


    clip feeder


    Specifications:

    ModelMAC4-600FMAC4-800FMAC4-1000FMAC4-1300F
    Stock Width(mm)70~60070~80070~100070~1300
    Stock Thickness(mm)0.6~6.00.6~6.00.6~6.00.6~6.0
    Max.Coil Weight(kg)50005000700010000
    Max.Coil O.D.(mm)1400140014001400
    Coil I.D.(mm)508508508508
    Feed Length(mm)~500*~500*~500*~500*
    Max.Line Speed(m/min)16~2416~2416~2416~24
    Work Roll Number(piece)upper 6/lower 5upper 6/lower 5upper 6/lower 5upper 6/lower 5
    Feed Roll number(set)1111
    Main MotorAC7.5AC11.0AC11.0AC11.0
    Mandrel ExpansionHydrauilcHydrauilcHydrauilcHydrauilc
    Reel Motor(kw)2.22.23.77.5
    Power(v)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.49


    Straightening Performance:

    ModelMAC4-600FMAC4-800FMAC4-1000FMAC4-1300F
    Stock Thickness
    (mm)
    0.8~2.360080010001300
    2.8933933
    3.2714714714
    4.0457457457457
    4.5361361361361
    5.0293293293293
    6.0203203203203

    Products:


    1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.
