    Feeder Cutting Decoiler And Straightener Mechanical Shearing Machine High Degree Automation

    Ask Lasest Price
    Brand Name : RUIHUI
    Model Number : MAC4-400SL
    Certification : CE, ISO certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Feeder Cutting Decoiler And Straightener Mechanical Shearing Machine High Degree Automation


    Mechanical shearing machine MAC4-400SL automatic feeder cutting


    Automatic feeder shearing line is the automatic cutting of all kinds of metal coils for various cold-rolled steel coils, hot rolled coils, stainless steel coils, galvanized steel coils, silicon steel and surface coated. The production line for cutting off.


    It has four major steps of unwinding, leveling, feeding and shearing. The coil material is unrolled, leveled, fed, and sheared into sheets of the required width. It is widely used in automobile, hardware, computer, electronics and other processing and manufacturing. industry.


    The emergence of automatic feeder shearing production line fundamentally solves the problems of high risk, poor shear dimensional accuracy, poor production efficiency and low productivity in traditional manual feeding shear production.


    The four processes of unwinding, leveling, feeding and shearing of Ruihui automatic feeder cutting production line correspond to four kinds of equipments, and the equipment used for unwinding of rolls is heavy material frame.


    The equipment used for flattening the internal stress of the material is a medium plate leveling machine or a thick plate leveling machine (selected according to the thickness of the material), and is used for the stepping feeding of the NC feeder or the air feeder for the shearing board. Mechanical shearing machine or hydraulic shearing machine for cutting.


    At present, the most used group line type of automatic feeder cutting production line is the combination of MT series heavy material frame-MAC series medium plate leveling machine-MAC series NC servo feeder-mechanical shearing machine.


    It can be used for automatic cutting production of various width plates with thickness of 0.5-3.0mm and width of 0-2500mm.


    In actual use, Ruihui heavy-duty material frame realizes unwinding and conveying of the plate, and the medium-plate leveling machine performs precision leveling internal stress treatment on the plate.


    The NC feeder realizes automatic feeding according to the information such as the size, shear quantity and speed of the plate actually input by the customer. The shearing machine realizes precise cutting and cutting, the whole line has high automation degree, the precision is stable and reliable, and the operation is simple and convenient.


    It is the most reliable and effective method for material blanking. At the same time, according to the actual customer's materials and shearing process, there are various options and customizations to meet the needs of customers for diversified, multi-functional and efficient production.


    Specification:


    ModelMAC4-400MAC4-600MAC4-800MAC4-1000MAC4-1300
    Stock Width(mm)70~40070~60070~80070~100070~1300
    Stock Thickness(mm)0.6~6.00.6~6.00.6~6.00.6~6.00.6~6.0
    Max.Coil Weight(kg)50005000700070007000
    Max.Coil O.D.(mm)14001400140014001400
    Coil I.D.(mm)508508508508508
    Feed Length(mm)~500*~500*~500*~500*~500*
    Max.Line Speed(m/min)16~2416~2416~2416~2416~24
    Work Roll Number(piece)upper 4/lower 3upper 4/lower 3upper 4/lower 3upper 4/lower 3upper 4/lower 3
    Feed Roll number(set)11111
    Main MotorAC5.5AC7.5AC7.5AC11.0AC11.0
    Mandrel ExpansionHydrauilcHydrauilcHydrauilcHydrauilcHydrauilc
    Reel Motor(kw)2.22.23.73.73.7
    Power(v)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.490.49


    Straightening Performance:


    ModelMAC4-400MAC4-600MAC4-80MAC4-1000MAC4-1300
    Stock Thickness
    (mm)
    0.6~1.340060080010001300
    2.0
    2.3
    2.51170
    2.8933933
    3.2714714714
    4.0457457457457
    4.5361361361361361
    5.0293293293293293
    6.0203203203203203


    FAQ:


    Q1:What kinds of machines do you have?

    Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener

    Feeder,Transfer systems,Press Feeding Line., etc

    Q2:Is your equipment standard or customized?

    Both, we can OEM & ODM with customers.

    Q3:What are your equipments certification?

    All our items are coming with CE certifications.

    Q4:How did your company's quality system work?

    “QUALITY IS OUR CULTURE” Our quality is not the best in the world, and the price is not the

    cheapest. But we can provide you excellent products to defeat your competitors.

    Q5:How long is the warranty period of the machine?

    We offer free service with a warranty period of one year, If it is operate in reasonable, the

    machine can be used more than 10 years.

    Q6: Is it possible to be a foreign agent and distributor?

    If you are confidence and excellent service for after-sales, then welcome to be our agents or

    distributors all over the world.

    Q7:What’s your payment?

    T/T,D/P,L/C,Western Union., etc

    Q8:What’s the delivery?

    “TIME IS GOLD” for you and for us, so we have professional team work and production line can

    make nice quality in short time.


    Service:

    1. Pre-Sales Service:We have professional designers to meet the different requirement.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.
