    3 In 1 Coil Straightener Feeder Machines For 0.6-6.0mm Thickness Steel Coil

    Ask Lasest Price
    Brand Name : RUIHUI
    Model Number : MAC4-800
    Certification : CE ISO
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 30 Sets Per Month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    3 In 1 Coil Straightener Feeder Machines For 0.6-6.0mm Thickness Steel Coil

    3 In 1 Coil Feeder Straightener Machines For 0.6-6.0mm Thickness Steel Coil


    Machine main specification (MAC4-800)


    1. Material thickness 0.6-6.0mm
    2. Mateiral width 70-800mm

    3. Coil I.D. 508mm (can be customized)

    4. Coil O.D. 1200mm

    5. Coil weight 3000kg (can be customized)

    6. Mandrel expansion term Hydraulic expansion

    7. Straightening roller Upper 4/ Lower 3

    8. Main Motor 7.5kw

    9. Uncoiler motor 3.7Kw

    10. AC Power 380V/415V 3 phase 50HZ(can be customized)


    Specification:


    Specification
    ModelMAC4-400MAC4-600MAC4-800MAC4-1000MAC4-1300
    Stock Width(mm)70~40070~60070~80070~100070~1300
    Stock Thickness(mm)0.6~6.00.6~6.00.6~6.00.6~6.00.6~6.0
    Max.Coil Weight(kg)50005000700070007000
    Max.Coil O.D.(mm)14001400140014001400
    Coil I.D.(mm)508508508508508
    Feed Length(mm)~500*~500*~500*~500*~500*
    Max.Line Speed(m/min)16~2416~2416~2416~2416~24
    Work Roll Number(piece)upper 4upper 4upper 4upper 4upper 4
    down 3down 3down 3down 3down 3
    Feed Roll number(set)11111
    Main MotorAC5.5AC7.5AC7.5AC11.0AC11.0
    Mandrel ExpansionHydrauilcHydrauilcHydrauilcHydrauilcHydrauilc
    Reel Motor(kw)2.22.23.73.73.7
    Power(v)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.490.490.49

    Straightening Performance
    ModelMAC4-400MAC4-600MAC4-800MAC4-1000MAC4-1300
    Stock Thickness (mm)0.6~1.340060080010001300
    2.0
    2.3
    2.51170
    2.8933933
    3.2714714714
    4.0457457457457
    4.5361361361361361
    5.0293293293293293
    6.0203203203203203


    FAQ:


    Q1:What kinds of machines do you have?

    Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener

    Feeder,Transfer systems,Press Feeding Line., etc

    Q2:Is your equipment standard or customized?

    Both, we can OEM & ODM with customers.

    Q3:What are your equipments certification?

    All our items are coming with CE certifications.

    Q4:How did your company's quality system work?

    “QUALITY IS OUR CULTURE” Our quality is not the best in the world, and the price is not the

    cheapest. But we can provide you excellent products to defeat your competitors.

    Q5:How long is the warranty period of the machine?

    We offer free service with a warranty period of one year, If it is operate in reasonable, the

    machine can be used more than 10 years.

    Q6: Is it possible to be a foreign agent and distributor?

    If you are confidence and excellent service for after-sales, then welcome to be our agents or

    distributors all over the world.

    Q7:What’s your payment?

    T/T,D/P,L/C,Western Union., etc

    Q8:What’s the delivery?

    “TIME IS GOLD” for you and for us, so we have professional team work and production line can

    make nice quality in short time.


    Service:


    1. Pre-Sales Service:We have professional designers to meet the different requirement.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.
