    Nc Servo Feeder Decoiler Straightener Feeder RUIHUI Coil Processing Equipment

    3 In 1 Nc Servo Feeder Decoiler Straightener Feeder With Power Press Machines


    Description:


    Coil Side Guides


    Material width adjustment gear wheel device has unique design,providing the operator mare secure,efficient,simple feeding setting adjustment

    Large straightening roll adjustment hand wheels has been adopted.Symbols are used for the indicators,improving repeatability and permitting easy numerical control setting.


    Specification:


    Specification
    ModelMAC3-300SLMAC3-400SLMAC3-600SL
    Stock Width(mm)50~30050~40050~600
    Stock Thickness(mm)0.3~4.5
    Max. Coil Weight(Kg)300030003000
    Max. Coil O.D.(mm)120012001200
    Max. Coil I.D.(mm)508508508
    Feed Length(mm)~400~400~400
    Max. Line Speed(m/min)16~2416~2416~24
    Work Roll Number(pcs)upper4/lower3
    Feed Roll Number(pcs)111
    Main Motor(KW)AC 4.4AC 4.4AC 4.4
    Mandrel ExpansionPneumatic/Hydraulic
    Reel Motor(KW)1.51.51.5
    Power(V)3 Phase 220V/380V/50HZ
    Operating Air(Mpa)0.490.490.49

    Straightening Performance
    ModelMAC3-300SLMAC3-400SLMAC3-600SL
    Stock Thickness (mm)0.3-0.8300400600
    1
    1.2
    1.6590
    1.8500
    2430
    2.3230360
    2.8160370290
    3.2150300250
    4.5110160160


    FAQ:


    Q1:What kinds of machines do you have?

    Our main products are:Nc Servo Roll Feeder,Uncoiler, Straightener, 3 in1 Straightener

    Feeder,Transfer systems,Press Feeding Line., etc

    Q2:Is your equipment standard or customized?

    Both, we can OEM & ODM with customers.

    Q3:What are your equipments certification?

    All our items are coming with CE certifications.

    Q4:How did your company's quality system work?

    “QUALITY IS OUR CULTURE” Our quality is not the best in the world, and the price is not the

    cheapest. But we can provide you excellent products to defeat your competitors.

    Q5:How long is the warranty period of the machine?

    We offer free service with a warranty period of one year, If it is operate in reasonable, the

    machine can be used more than 10 years.

    Q6: Is it possible to be a foreign agent and distributor?

    If you are confidence and excellent service for after-sales, then welcome to be our agents or

    distributors all over the world.

    Q7:What’s your payment?

    T/T,D/P,L/C,Western Union., etc

    Q8:What’s the delivery?

    “TIME IS GOLD” for you and for us, so we have professional team work and production line can

    make nice quality in short time.


    Service:

    1. Pre-Sales Service:We have professional designers to meet the different requirement.

    2. After-Sales service:We have an efficient team to meet 24*7 all day service.

    3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.

    4. Engineers can provide service machinery overseas.



    Why choose us?
    1st,We have a high level of technical research and development team;
    2nd,We can provide the design and planning of the whole plant to realize the turnkey project;
    3rd, our philosophy: quality is the social responsibility;
    4th,our products have been recognized by the market, in the major automotive OEM, home appliance industry, hardware industry has been applied;
    5th,We have a highly effective after-sales service team and get customer approval.
